Aluminum Telescopic Slides

260 Series Light-Duty Aluminum Slides

The thinnest 2U ball bearing slide on the market.

The 260QD slide has a thin profile of .25” wide x 3.00” tall full extension function slide and can be hard mounted or rack mounted to best suit your needs. Made from extruded aluminum and clear anodized, this slide is ideal for applications where the electronic chassis is too wide for conventional slides.


For Product Support, please contact your Local Representative 714-665-4400 or email

  • Tech Specs
  • Custom Features
  • Custom Solutions
  • Downloads
260 Standard Features
  • .25” wide x 3.00”
  • Material: Aluminum
  • Finish:  Clear anodize
  • Load Rating: up to 150 lbs.
  • Slide positive lock open
  • Inner member disconnect
  • For rack mounting- Standard bracketry available:  BK-69, BK-70, BK-71, BK-72


While this slide has a thin profile, its 2U form factor allows it to carry over 150 lbs.  Modifications to the basic JES 260QD series have been proven to meet a wide range of conditions such as ease of installation, high cycle, salt spray resistance, acceptance to numerous chemicals and fluids, and can withstand UL type testing for rack mounted equipment.

  • Material: Aluminum Extrusion
  • Finish:  Clear Anodize – Color/Hard anodize options available
  • Standard Lengths 10″-30″ – Custom Lengths Available
  • Travel: Full/Over/Under-travel Available
  • Slide Hole Patterns:  Size and location can be modified
  • Mounting Options:
    • Standard Brackets
    • Modified Brackets
    • Custom Mounting Plates
  • COTS Trays
  • Ruggedized Assemblies
  • Integrated Kits
  • Sheet Metal Assemblies
  • Cable Management
  • Bracketry
  • Hardware Kits
  • Trays
  • Precision Machined Components


The inner member includes a quick disconnect for more efficient installation and servicing.
